2024 Harn ALUNAN T Slim Drawer System www.dorsetaustralia.com.au
Limitless Possibilities Standard Drawers 3 2 Harn ALUNAN T | Index
Harn ALUNAN T Slim Wall Drawer System www.dorsetaustralia.com.au Harn ALUNAN T - S Drawers - 88mm Pages 8-11 Harn ALUNAN T - T Drawers - 120mm Pages 12-15 Harn ALUNAN T - K Drawers - 175mm Pages 16-19 Harn ALUNAN T - HS Standard Drawer - 208mm Pages 20-21 Harn ALUNAN T - FS Standard Drawer - 272mm Pages 22-23 Harn ALUNAN T - Accessories Pages 24-25 Harn ALUNAN T - Assembly Instructions Pages 26-31 3 Harn ALUNAN T | Index 1300 121 800 | www.dorsetaustralia.com.au 3 1 1 2 1 2 3 1 39
4 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Harn ALUNAN T Introduction Harn ALUNAN T | Introduction Load capacity of 35kg & 60kg NEW Matt White Silk Finish Manufactured using superior roll forming process Complete Box Pack Available in drawer lengths from 270mm to 550mm Designed to make your job as easy and efficient as possible, Harn Alunan T is already fully integrated with the best in design and CNC software, with fully functioning models available in the most commonly used programs such as Microvellum, Planit (CabinetVision), and CabMaster. . . Ready for your project, no matter your software Phillips Head Adjustment Screws
Harn ALUNAN T 5 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Introduction The Harn ALUNAN T now has the drawer front adjustment on the inside of the drawer This keeps you from getting into a pickle when you're in a tight spot trying to adjust your drawer fronts. This feature is particularly helpful when your up against a fridge cabinet or close to an internal corner. Internal Drawer Front Adjustment... 3. Toolless Front Bracket Fitting... 1. The Harn ALUNAN T features Harn's new and improved front bracket which is now toolless for installation Simply push the front bracket into the standard 10mm pre-drilled holes and flip the bracket up into the up-right position. In this one simple motion the split plastic dowels are expanded out and the front bracket is fixed in place. Harn ALUNAN T | Introduction Pateted Drawer Tilt Adjustment... 4. ALUNAN T features an all new industry leading tilt adjustment mechanism This patented system tilts the drawer front both backwards and forwards meaning that any ‘weather boarding’ affect that might occur with a row of higher drawer fronts can be easily corrected 1 2 Standard Drawer K - Height Adjustment Inner Drawer Locking Piece for RPF875 - Assembly 3 1 2 1 Standard Drawer S / T / K / HS / FS - Front Tilt Adjustment 2 Technical Information - Adjustment Simple Push-In Drawer Front Brackets... 2. This new front bracket replaces Harn's long standing hook style front bracket This means you can fit the drawer fronts in any order (not only having to work from the top down). This improvement helps to align the Alunan Drawer system with other well known drawer brands.
© Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Introduction Harn ALUNAN T 6 Harn ALUNAN T | Introduction
Easily fine-tune the front panel angle with just a few straight forward steps. INSTALLATION 3-Dimensional Adjustment, Flexible and Easily Accessible ALUNAN T offers effortless adjustment options on three dimensions - height, side and tilt - making it simple to customize and access with ease. Tilt Adjustment Height & Side Adjustment ALUNAN T can be installed efficiently with adjustment options for height and side. Experience seamless versatility and user-friendly functionality for perfect alignment in any space. © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Introduction Harn ALUNAN T 7 Harn ALUNAN T | Introduction 1300 121 800 | www.dorsetaustralia.com.au
Harn ALUNAN T 8 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. S Standard Drawer S Standard Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Steel drawer side 88mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser S 88mm Back Height 74mm Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per AKT8827S.SWH.BOX Silk White 270mm 35kg 178 set AKT8835S.SWH.BOX Silk White 350mm 35kg 178 set AKT8840S.SWH.BOX Silk White 400mm 35kg 118 set AKT8845S.SWH.BOX Silk White 450mm 35kg 118 set AKT8850S.SWH.BOX Silk White 500mm 35kg 118 set AKT8855S.SWH.BOX Silk White 550mm 35kg 118 set A6AKT8845S.SWH.BOX Silk White 450mm 60kg 118 set A6AKT8850S.SWH.BOX Silk White 500mm 60kg 118 set A6AKT8855S.SWH.BOX Silk White 550mm 60kg 118 set Harn ALUNAN T | S Standard Drawer
Harn ALUNAN T 9 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. S Standard Drawer TM13S - 35kg TM16S - 60kg S Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - S 9 32 20 37.5 37.5 min. 33 min. 49.5 min. 76* 14.0 32 51 min. 109* Front overlay Built in tolerance compensation ±1.0mm Bottom panel width + 47mm For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm 5.0 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 74mm Back panel 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 29 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - S 9 32 20 37.5 37.5 min. 33 min. 49.5 min. 76* 14.0 32 51 min. 109* Front overlay Built in tolerance compensation ±1.0mm Bottom panel width + 47mm For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm 5.0 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 74mm Back panel 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 29 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm Standard Drawer - S 9 32 20 37.5 37.5 min. 33 min. 49.5 min. 76* 14.0 32 51 min. 109* Front overlay Built in tolerance compensation ±1.0mm Bottom panel width + 47mm For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm 5.0 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 74mm Back panel 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 29 Harn ALUNAN T | S Standard Drawer
Harn ALUNAN T 10 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. S Inner Drawer S Inner Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Steel drawer side 88mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser S 88mm High 88mm Back Height 74mm Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per AKI8827S.SWH.BOX Silk White 270mm 35kg 178 set AKI8835S.SWH.BOX Silk White 350mm 35kg 178 set AKI8840S.SWH.BOX Silk White 400mm 35kg 118 set AKI8845S.SWH.BOX Silk White 450mm 35kg 118 set AKI8850S.SWH.BOX Silk White 500mm 35kg 118 set AKI8855S.SWH.BOX Silk White 550mm 35kg 118 set A6AKI8845S.SWH.BOX Silk White 450mm 60kg 118 set A6AKI8850S.SWH.BOX Silk White 500mm 60kg 118 set A6AKI8855S.SWH.BOX Silk White 550mm 60kg 118 set Harn ALUNAN T | S Inner Drawer
Harn ALUNAN T 11 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. S Inner Drawer TM13S - 35kg TM16S - 60kg S Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - S Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 74mm Back panel 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 9 32 20 37.5 37.5 min. 33 min. 49.5 min. 76* min. 109* Built in tolerance compensation ±1.0mm 5.0 29 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - S Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 74mm Back panel 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 9 32 20 37.5 37.5 min. 33 min. 49.5 min. 76* min. 109* Built in tolerance compensation ±1.0mm 5.0 29 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm Inner Drawer - S Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 74mm Back panel 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 9 32 20 37.5 37.5 min. 33 min. 49.5 min. 76* min. 109* Built in tolerance compensation ±1.0mm 5.0 29 Harn ALUNAN T | S Inner Drawer
Harn ALUNAN T 12 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. T Standard Drawer T Standard Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Steel drawer side 120mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser 120mm High 120mm Back Height 106mm Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per AKT12027T.SWH.BOX Silk White 270mm 35kg 135 set AKT12035T.SWH.BOX Silk White 350mm 35kg 135 set AKT12040T.SWH.BOX Silk White 400mm 35kg 90 set AKT12045T.SWH.BOX Silk White 450mm 35kg 90 set AKT12050T.SWH.BOX Silk White 500mm 35kg 90 set AKT12055T.SWH.BOX Silk White 550mm 35kg 90 set A6AKT12045T.SWH.BOX Silk White 450mm 60kg 90 set A6AKT12050T.SWH.BOX Silk White 500mm 60kg 90 set A6AKT12055T.SWH.BOX Silk White 550mm 60kg 90 set Harn ALUNAN T | T Standard Drawer
Harn ALUNAN T 13 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. T Standard Drawer TM13S - 35kg TM16S - 60kg Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - T Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 106mm Back panel 29 9 22 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 51 32 min. 108* 14.0 min. 141* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Front overlay Bottom panel width + 47mm 5.0 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - T Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 106mm Back panel 29 9 22 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 51 32 min. 108* 14.0 min. 141* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Front overlay Bottom panel width + 47mm 5.0 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm Standard Drawer - T Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 106mm Back panel 29 9 22 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 51 32 min. 108* 14.0 min. 141* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Front overlay Bottom panel width + 47mm 5.0 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 Harn ALUNAN T | T Standard Drawer
Harn ALUNAN T 14 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. T Inner Drawer T Inner Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Steel drawer side 120mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser 120mm High 120mm Back Height 106mm Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per AKI12027T.SWH.BOX Silk White 270mm 35kg 135 set AKI12035T.SWH.BOX Silk White 350mm 35kg 135 set AKI12040T.SWH.BOX Silk White 400mm 35kg 90 set AKI12045T.SWH.BOX Silk White 450mm 35kg 90 set AKI12050T.SWH.BOX Silk White 500mm 35kg 90 set AKI12055T.SWH.BOX Silk White 550mm 35kg 90 set A6AKI12045T.SWH.BOX Silk White 450mm 60kg 90 set A6AKI12050T.SWH.BOX Silk White 500mm 60kg 90 set A6AKI12055T.SWH.BOX Silk White 550mm 60kg 90 set Harn ALUNAN T | T Inner Drawer
Harn ALUNAN T 15 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. T Inner Drawer TM13S - 35kg TM16S - 60kg Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - T 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 29 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 106mm Back panel 9 22 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 min. 108* min. 141* 5.0 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - T 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 29 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 106mm Back panel 9 22 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 min. 108* min. 141* 5.0 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm Inner Drawer - T 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 29 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 106mm Back panel 9 22 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 min. 108* min. 141* 5.0 Harn ALUNAN T | T Inner Drawer
Harn ALUNAN T 16 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. K Standard Drawer K Standard Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Drawer side 175mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser Kit Part No. Codes 175mm High 175mm Back Height 161mm Part No. Finish Length Weight Pallet Qty Sold Per AKT17527K.SWH.BOX Silk White 270mm 35kg 90 set AKT17535K.SWH.BOX Silk White 350mm 35kg 90 set AKT17540K.SWH.BOX Silk White 400mm 35kg 90 set AKT17545K.SWH.BOX Silk White 450mm 35kg 90 set AKT17550K.SWH.BOX Silk White 500mm 35kg 90 set AKT17555K.SWH.BOX Silk White 550mm 35kg 90 set A6AKT17545K.SWH.BOX Silk White 450mm 60kg 60 set A6AKT17550K.SWH.BOX Silk White 500mm 60kg 60 set A6AKT17555K.SWH.BOX Silk White 550mm 60kg 60 set Harn ALUNAN T | K Standard Drawer
Harn ALUNAN T 17 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. K Standard Drawer TM13S - 35kg TM16S - 60kg Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - K Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 161mm Back panel 29 Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 163* 37.5 37.5 64 32 32 14.0 51 min. 196* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Bottom panel width + 47mm Front overlay 32 9 40 32 32 5.0 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - K Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 161mm Back panel 29 Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 163* 37.5 37.5 64 32 32 14.0 51 min. 196* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Bottom panel width + 47mm Front overlay 32 9 40 32 32 5.0 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm Standard Drawer - K Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 161mm Back panel 29 Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 163* 37.5 37.5 64 32 32 14.0 51 min. 196* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Bottom panel width + 47mm Front overlay 32 9 40 32 32 5.0 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 Harn ALUNAN T | K Standard Drawer
Harn ALUNAN T 18 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. K Inner Drawer K Inner Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Drawer side 175mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser Kit Part No. Codes 175mm High 175mm Back Height 161mm Part No. Finish Length Weight Pallet Qty Sold Per AKI17527K.SWH.BOX Silk White 270mm 35kg 90 set AKI17535K.SWH.BOX Silk White 350mm 35kg 90 set AKI17540K.SWH.BOX Silk White 400mm 35kg 90 set AKI17545K.SWH.BOX Silk White 450mm 35kg 90 set AKI17550K.SWH.BOX Silk White 500mm 35kg 90 set AKI17555K.SWH.BOX Silk White 550mm 35kg 90 set A6AKI17545K.SWH.BOX Silk White 450mm 60kg 60 set A6AKI17550K.SWH.BOX Silk White 500mm 60kg 60 set A6AKI17555K.SWH.BOX Silk White 550mm 60kg 60 set Harn ALUNAN T | K Inner Drawer
Harn ALUNAN T 19 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. K Inner Drawer TM13S - 35kg TM16S - 60kg Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - K 29 32 9 40 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 min. 163* min. 196* 5.0 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 161mm Back panel Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - K 29 32 9 40 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 min. 163* min. 196* 5.0 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 161mm Back panel Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Inner Drawer - K 29 32 9 40 32 32 Built in tolerance compensation ±1.0mm 37.5 37.5 min. 33 min. 49.5 min. 163* min. 196* 5.0 Width = internal cabinet width - 75mm Bottom panel Length (Wooden Back) = drawer length - 24mm Width = internal cabinet width - 87mm Height = 161mm Back panel Cutting Dimensions for Front Panel Width = Internal cabinet width - 132mm 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 Harn ALUNAN T | K Inner Drawer
Harn ALUNAN T 20 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. HS Standard Drawer HS Standard Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Drawer side 208mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser 208mm Back Height 194mm 208mm High Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per AKT20827HS.SWH.BOX Silk White 270mm 35kg 178 set AKT20835HS.SWH.BOX Silk White 350mm 35kg 178 set AKT20840HS.SWH.BOX Silk White 400mm 35kg 118 set AKT20845HS.SWH.BOX Silk White 450mm 35kg 118 set AKT20850HS.SWH.BOX Silk White 500mm 35kg 118 set AKT20855HS.SWH.BOX Silk White 550mm 35kg 118 set A6AKT20845HS.SWH.BOX Silk White 450mm 60kg 118 set A6AKT20850HS.SWH.BOX Silk White 500mm 60kg 118 set A6AKT20855HS.SWH.BOX Silk White 550mm 60kg 118 set Harn ALUNAN T | HS Standard Drawer
Harn ALUNAN T 21 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. HS Standard Drawer TM13S - 35kg TM16S - 60kg Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - HS 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 9 32 32 32 12 32 32 Bottom panel Width = internal cabinet width - 75mm Length (Wooden Back) = drawer length - 24mm Back panel Width = internal cabinet width - 87mm Height = 194mm Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 196* 5.0 37.5 37.5 96 32 32 14.0 51 min. 229* Bottom panel width + 47mm Front overlay 29 For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - HS 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 9 32 32 32 12 32 32 Bottom panel Width = internal cabinet width - 75mm Length (Wooden Back) = drawer length - 24mm Back panel Width = internal cabinet width - 87mm Height = 194mm Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 196* 5.0 37.5 37.5 96 32 32 14.0 51 min. 229* Bottom panel width + 47mm Front overlay 29 For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - HS 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 9 32 32 32 12 32 32 Bottom panel Width = internal cabinet width - 75mm Length (Wooden Back) = drawer length - 24mm Back panel Width = internal cabinet width - 87mm Height = 194mm Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 196* 5.0 37.5 37.5 96 32 32 14.0 51 min. 229* Bottom panel width + 47mm Front overlay 29 For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Harn ALUNAN T | HS Standard Drawer
Harn ALUNAN T 22 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. FS Standard Drawer FS Standard Drawer •• Soft close roller bearing concealed runners •• Full extension with synchro control •• Drawer side 272mm •• Load capacity of 35kg or 60kg •• Quick assembly •• Flexible 2-dimensional front adjustment •• Sylent integrated cushioning system •• Integrated lateral stabiliser 272mm Back Height 258mm 272mm High Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per AKT27227FS.SWH.BOX Silk White 270mm 35kg 178 set AKT27235FS.SWH.BOX Silk White 350mm 35kg 178 set AKT27240FS.SWH.BOX Silk White 400mm 35kg 118 set AKT27245FS.SWH.BOX Silk White 450mm 35kg 118 set AKT27250FS.SWH.BOX Silk White 500mm 35kg 118 set AKT27255FS.SWH.BOX Silk White 550mm 35kg 118 set A6AKT27245FS.SWH.BOX Silk White 450mm 60kg 118 set A6AKT27250FS.SWH.BOX Silk White 500mm 60kg 118 set A6AKT27255FS.SWH.BOX Silk White 550mm 60kg 118 set Harn ALUNAN T | FS Standard Drawer
Harn ALUNAN T 23 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. FS Standard Drawer TM13S - 35kg TM16S - 60kg Space Requirements & Front Installation Dimensions Back Installation Dimensions Cabinet Profile Screw Positions Cutting Dimensions for 16mm Chipboard Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm Standard Drawer - FS 96 32 96 32 128 32 32 37 9 5 128 160 192 224 32 32 32 32 Bottom panel Width = internal cabinet width - 75mm Length (Wooden Back) = drawer length - 24mm Back panel Width = internal cabinet width - 87mm Height = 258mm 29 32 32 Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 260* 37.5 37.5 32 128 32 14.0 51 min. 293* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Bottom panel width + 47mm Front overlay 32 32 64 32 12 9 5.0 Harn ALUNAN T | FS Standard Drawer Cabinet Profile Screw Positions Space Requirements and Front Installation Dimensions Back Installation Dimensions Drawer Length TM13S Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Min. internal cabinet depth = drawer length + 3 mm Actual loss of extension = 0 mm Drawer Length TM16S * Incl. 2mm tilt adjustment Cutting Dimensions for 16mm Chipboard 270 / 300 / 350mm 400mm 450mm 500 / 550mm 400mm 450mm 500 / 550mm 600 / 650mm Standard Drawer - FS 5 37 9 160 192 224 288 96 32 96 32 128 32 128 32 32 32 37 9 5 128 160 192 224 32 32 32 32 Bottom panel Width = internal cabinet width - 75mm Length (Wooden Back) = drawer length - 24mm Back panel Width = internal cabinet width - 87mm Height = 258mm 29 32 32 Built in tolerance compensation ±1.0mm min. 33 min. 49.5 min. 260* 37.5 37.5 32 128 32 14.0 51 min. 293* For press-in and expansion front fixing brackets to pre-drill Ø10mm x 12mm Bottom panel width + 47mm Front overlay 32 32 64 32 12 9 5.0
Harn ALUNAN T 24 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Harn ALUNAN T | Accessories Accessories Knock In Tool Marking Devices RMD.91550.25 RMD.92330.25 Article No. Drawer Front Marking Jigs Article No. Railing Marking Template 23 23 23 46 Marking Devices Knock In Tool Marking Devices RMD.91550.25 RMD.92330.25 Article No. Drawer Front Marking Jigs Article No. Railing Marking Template 23 23 23 46 42 Marking Devices Rail Marking Template •• Quick and easy jig for marking fixing hole positions when installing gallery rails •• Easy marking with a pencil on the back of the drawer front for accuracy of positioning when fixings for gallery rails •• Material: Nylon •• Finish: Black (BL) Part No. Finish Box Qty Per RMD.92330 BL 10 ea Drawer Front Marking Jigs •• Quick and easy jig when installing drawer fronts on site •• Leaves small indentations on the back of the drawer front for accuracy of positioning when fixing front brackets •• Material: Nylon •• Finish: Black (BL) Part No. Finish Box Qty Per RMD.91550 BL 5 Set
Harn ALUNAN T 25 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Harn ALUNAN T | Accessories Accessories Alunan Safety Lock •• Locks the drawer on to runner securely •• Finish: Grey (GY) Part No. Description Box Qty Per ALC210L.GY Left Hand Side 200 ea ALC210R.GY Right Hand Side 200 ea Alunan S Lite Grey • Used to l Accessories Installation 1 2 Alunan Safety Lock Lite Grey • Used to lock drawer to runner 35 Accessories Installation Lock Unlock 210.000 1 2 Installation Unlock Lock Inner Drawer Front Locking Piece - Square Style •• Refer to page 149 for installation Part No. Box Qty Sold Per RLP208.000 10 ea Standard Drawer Front Locking Piece •• Refer to page 148 for installation Part No. Box Qty Sold Per RLP201.000 10 ea Spacer 25mm •• Used to space cabinet profiles away from the cabinet side on internal drawers •• Two pieces required per cabinet profile Part No Box Qty Sold Per T207.00 12 ea
Harn ALUNAN T 26 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Harn ALUNAN T | Assembly Instructions Assembly Instructions Standard Drawer S/T/K - Assembly Standard Drawer HS/FS - Assembly Standard Drawer S/T - Front Panel Assembly 4 4 5 3 2 1 2 3 4 1 2 3 1 3 1 2 Technical Information - Assembly 37 4 5 3 2 3 4 1 2 3 1 3 1 2 Technical Information - Assembly 4 5 3 2 1 2 3 4 1 2 3 1 3 1 2 Technical Information - Assembly
27 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. 1300 121 800 | www.dorsetaustralia.com.au Harn ALUNAN T | Assembly Instructions Assembly Instructions Harn ALUNAN T Standard Drawer K - Front Panel Assembly Standard Drawer HS/FS - Front Panel and Side Extend Assembly 4 5 3 2 1 3 1 2 37 Standard Drawer HS / FS - Front Panel and Side Extend Assembly Inner Drawer S / T - Assembly Standard Drawer HS Rectangular Rail - Front Panel and Railing Assembly 1 8 5 6 7 4 1 2 3 7 5 6 1 2 3 4 Technical Information - Assembly Standard Drawer S/T - Assembly Standard Drawer HS / FS - Front Panel and Side Extend Assembly Inner Drawer S / T - Assembly Inner Drawer K - Assembly Standard Drawer HS Rectangular Rail - Front Panel and Railing Assembly 2 3 1 1 8 5 6 7 4 1 2 3 7 5 6 1 2 3 4 Technical Information - Assembly
Harn ALUNAN T 28 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Assembly Instructions Harn ALUNAN T | Assembly Instructions Inner Drawer K - Assembly Drawer Insertion Inner Drawer K - Assembly 2 2 3 1 38 3 1 1 2 1 2 3 Standard Drawer S/T/HS/FS - SIde Adjustment 1 1 2 3
Harn ALUNAN T 29 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Assembly Instructions Harn ALUNAN T | Assembly Instructions Standard Drawer K - Height Adjustment Standard Drawer K - Height Adjustment 3 1 Standard Drawer S / T / K / HS / FS - Front Tilt Adjustment 2 Technical Information - Adjustment Standard Drawer K - Side Adjustment Standard Drawer S/T/HS/FS - Height Adjustment 3 1 1 2 1 39 3 1 1 2 1 39
Harn ALUNAN T 30 © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Assembly Instructions Harn ALUNAN T | Assembly Instructions Standard Drawer S/T/HS/FS - Front Tilt Adjustment Inner Drawer Locking Peice for RPF875 - Assembly 1 1 2 2 3 C Space Requirements 7mm min 10mm 1 2 Standard Drawer Locking Piece - Assembly Inner Drawer Locking Piece for RPF875 - Assembly 1 2 Standard Drawer S / T / K / HS / FS - Front Tilt Adjustment 40 1 1 2 2 3 C Space Requirements 7mm min 10mm 1 2 Standard Drawer K - Height Adjustment Standard Drawer Locking Piece - Assembly Inner Drawer Locking Piece for RPF875 - Assembly 3 1 2 1 Standard Drawer S / T / K / HS / FS - Front Tilt Adjustment 2 Technical Information - Adjustment 40 Standard Drawer Locking Piece - Assembly 1 1 2 2 3 C Space Requirements 7mm min 10mm 1 2 Standard Drawer K - Height Adjustment Standard Drawer Locking Piece - Assembly Inner Drawer Locking Piece for RPF875 - Assembly 3 1 2 1 Standard Drawer S / T / K / HS / FS - Front Tilt Adjustment 2 Technical Information - Adjustment 40
Harn ALUNAN T 31 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2024 All Rights Reserved. Specifications subject to change without notice. Assembly Instructions Harn ALUNAN T | Assembly Instructions Standard Drawer K - Front Panel Removal Standard Drawer HS/FS Side Extend - Removal Standard Drawer HS Rectangular Rail - Removal Standard Drawer HS / FS Side Extend - Removal Standard Drawer S / T - Front Panel Removal Drawer Removal 3 2 1 2 3 1 1 1 2 Standard Drawer K - Front Panel Removal 1 Technical Information - Removal 41 Standard Drawer HS Rectangular Rail - Removal Standard Drawer HS / FS Side Extend - Removal Standard Drawer S / T - Front Panel Removal Drawer Removal 3 2 1 2 3 1 1 1 2 Standard Drawer K - Front Panel Removal 1 Technical Information - Removal wer HS Rectangular Rail - Removal Standard Drawer HS / FS Side Extend - Removal wer S / T - Front Panel Removal val 2 wer K - Front Panel Removal 1 formation - Removal Drawer Removal Standard Drawer S/T - Front Panel Removal Standard Drawer HS Rectangular Rail - Removal Standard Drawer HS / FS Side Extend - Removal Standard Drawer S / T - Front Panel Removal Drawer Removal 3 2 1 2 3 1 1 1 2 Standard Drawer K - Front Panel Removal 1 Technical Information - Removal Standard Drawer HS Rectangular Rail - Removal S Standard Drawer S / T - Front Panel Removal 3 2 1 1 1 Standard Drawer K - Front Panel Removal 1 41 Drawer Removal - With Locking Clip Alunan Safety Lock Lite Grey • Used to lock drawer to runner Accessories Installation Lock Unlock 210.000 1 2 Installation Unlock Lock
Head Office & Distribution Centre: Postal Address: Phone: 1300 121 800 | Fax: 1300 121 850 Email: hello@dorsetaustralia.com.au 143 Allingham Street, Golden Square VIC 3555, Australia PO Box 2290, Bendigo VIC 3554 www.dorsetaustralia.com.au
