ZENTRA™ Slim Drawer System 02 © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. 84mm Drawer ZENTRA™ Slim Drawer System | 84mm Drawer ZENTRA™ Slim 84mm Drawer •• Slim double wall drawer with full-extension synchronized runners •• Soft close feature •• Drawer side height: 84mm •• Load capacity of 40kg •• Quick assembly & disassembly •• Silent runners •• Box Qty: 4 sets •• Durable powdercoated matt white finish 84mm High Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per ZWD8427.WH White 270mm 40kg 176 set ZWD8435.WH White 350mm 40kg 144 set ZWD8440.WH White 400mm 40kg 112 set ZWD8445.WH White 450mm 40kg 112 set ZWD8450.WH White 500mm 40kg 112 set Drawer base Back panel SY91.086 Basic component Slide mounting hole dimension The cabinet member dimensions Cabinet space requirements Drawer front connector mounting dimensions Drawer front drilling dimensions Mounting dimensions for the back panel Cutting dimensions of 16mm thick MDF
ZENTRA™ Slim Drawer System 03 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. ZENTRA™ Slim Drawer System | 84mm Drawer 84mm Drawer 115 NL+3 Drawer Slide Installation Dimensions Cutting Dimensions For Back & Base Panels Space Required ICW = Internal Cabinet Width NL = Normal Length NL = Nominal Length (mm) Drawer front installation dimensions Drawer front drilling dimensions Back panel installation dimensions Cabinet space requirements 115 min 47.5 min 15.5 47.5 min Back panel 192 224 256 37 9 14 NL-24 86 ICW-75 ICW-87 ICW B A A B Base NL-24mm 12 32 86 32 270 350 400 450 500 49 min 33 min 20 32 Side View Space Required NL+3 The cabinet front 37 Mounting
ZENTRA™ Slim Drawer System 04 © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. 116mm Drawer ZENTRA™ Slim Drawer System | 116mm Drawer ZENTRA™ Slim 116mm Drawer •• Slim double wall drawer with full-extension synchronized runners •• Soft close feature •• Drawer side height: 116mm •• Load capacity of 40kg •• Quick assembly & disassembly •• Silent runners •• Box Qty: 4 sets •• Durable powdercoated matt white finish 116mm High Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per ZWD11627.WH White 270mm 40kg 160 set ZWD11635.WH White 350mm 40kg 128 set ZWD11640.WH White 400mm 40kg 96 set ZWD11645.WH White 450mm 40kg 96 set ZWD11650.WH White 500mm 40kg 96 set Drawer base Back panel SY91.118 Basic component Slide mounting hole dimension The cabinet member dimensions Cabinet space requirements Drawer front connector mounting dimensions Drawer front drilling dimensions Mounting dimensions for the back panel Cutting dimensions of 16mm thick MDF
ZENTRA™ Slim Drawer System 05 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. ZENTRA™ Slim Drawer System | 116mm Drawer 116mm Drawer 150 NL+3 Drawer front installation dimensions Drawer front drilling dimensions Back panel installation dimensions Cabinet space requirements Drawer Slide Installation Dimensions Cutting Dimensions For Back & Base Panels Space Required 32 32 min 47.5 32 12 32 min 47.5 17 32 32 9 min 49 min 33 15.5 Side View Space Required Nominal Length (mm) Mounting min 150 118 ICW = Internal Cabinet Width NL = Normal Length Back panel NL-24 118 ICW-75 ICW-87 ICW B A A B Base NL-24mm 192 224 256 37 9 14 270 350 400 450 500 NL+3 The cabinet front 37
ZENTRA™ Slim Drawer System 06 © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. 167mm Drawer ZENTRA™ Slim Drawer System | 167mm Drawer ZENTRA™ Slim 167mm Drawer •• Slim double wall drawer with full-extension synchronized runners •• Soft close feature •• Drawer side height: 167mm •• Load capacity of 40kg •• Quick assembly & disassembly •• Silent runners •• Box Qty: 4 sets •• Durable powdercoated matt white finish 167mm High Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per ZWD16727.WH White 270mm 40kg 96 set ZWD16735.WH White 350mm 40kg 80 set ZWD16740.WH White 400mm 40kg 80 set ZWD16745.WH White 450mm 40kg 80 set ZWD16750.WH White 500mm 40kg 64 set Drawer base Back panel Dr SY91.167 Basic component Slide mounting hole dimension The cabinet member dimensions Cabinet space requirements Drawer front connector mounting dimensions Drawer front drilling dimensions Mounting dimensions for the back panel Cutting dimensions of 16mm thick MDF D D D
ZENTRA™ Slim Drawer System 07 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. ZENTRA™ Slim Drawer System | 167mm Drawer 167mm Drawer min 198 167 min 47.5 32 64 32 32 39 32 32 32 min33 min49 64 32 min 47.5 12 NL = Nominal Length (mm) Drawer Slide Installation Dimensions Cutting Dimensions For Back & Base Panels Space Required Mounting Drawer front installation dimensions Drawer front drilling dimensions Back panel installation dimensions Cabinet space requirements Side View Space Required 192 224 256 37 9 14 270 350 400 450 500 ICW = Internal Cabinet Width NL = Normal Length Back panel NL-24 167 ICW-75 ICW-87 ICW B A A B Base NL-24mm 198 NL+3 NL+3 Cabinet front min 37
ZENTRA™ Slim Drawer System 08 © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. 199mm Drawer ZENTRA™ Slim Drawer System | 199mm Drawer ZENTRA™ Slim 199mm Drawer •• Slim double wall drawer with full-extension synchronized runners •• Soft close feature •• Drawer side height: 199mm •• Load capacity of 40kg •• Quick assembly & disassembly •• Silent runners •• Box Qty: 4 sets •• Durable powdercoated matt white finish 199mm High Kit Part No. Codes Part No. Finish Length Weight Pallet Qty Sold Per ZWD19927.WH White 270mm 40kg 96 set ZWD19935.WH White 350mm 40kg 80 set ZWD19940.WH White 400mm 40kg 80 set ZWD19945.WH White 450mm 40kg 64 set ZWD19950.WH White 500mm 40kg 64 set Drawer base Back panel SY91.199 Basic component Slide mounting hole dimension The cabinet member dimensions Cabinet space requirements Drawer front connector mounting dimensions Drawer front drilling dimensions Mounting dimensions for the back panel Cutting dimensions of 16mm thick MDF
ZENTRA™ Slim Drawer System 09 1300 121 800 | www.dorsetaustralia.com.au © Copyright 2026 All Rights Reserved. Specifications subject to change without notice. ZENTRA™ Slim Drawer System | 199mm Drawer 199mm Drawer 32 64 32 32 64 32 32 min33 min49 min47.5 12 Mounting Drawer front installation dimensions Drawer front drilling dimensions Back panel installation dimensions Cabinet space requirements 32 64 32 min47.5 15.5 min 230 199 Drawer Slide Installation Dimensions Cutting Dimensions For Back & Base Panels 192 224 256 37 9 14 270 350 400 450 500 ICW = Internal Cabinet Width NL = Normal Length Back panel NL-24 199 ICW-75 ICW-87 ICW B A A B Base NL-24mm Space Required NL = Nominal Length (mm) 230 NL+3 Side View Space Required Cabinet front NL+3 Soft-closing Drawer 37
